物理特性/Physical Characteristics

尺寸 Dimensions:

160mm x 64mm x 97mm

重量 Weight:

140.5g

電壓 Voltage:

5±5%V

開機電流 Starting Current:

160mA

待機電流 Stand-by Current:

120mA

工作電流 Work Current:

330mA

性能指標/Performance Characteristics

傳感器像素 Image (Pixels):

640 pixels (H)x480 pixels (V)

光源 Light Source:

(Aimer) Red color LED; (Illumination) White color LED

旋轉/傾斜/偏轉 Roll / Pitch / Yaw:

360°(Roll), ±65°(Skew) , ±65°(Pitch)

打印對比度Print Contrast:

20% minimum reflective difference

接口支持 Interfaces Supported:

USB

運動容差Motion Tolerances:

>0.4m/s

解碼能力/Symbology Decode Capability

一維條碼/1-D:

Codabar,Code 39,Code 32 Pharmaceutical (PARAF),Interleaved 2 of 5,NEC 2 of 5,Code 93,Straight 2 of 5 Industial,Straight 2 of 5 IATA，Matrix 2 of 5，Code 11,Code 128,GS1-128,UPC-A,UPC-E ,EAN/JAN-8,EAN/JAN-13,MSI,GS1 DataBar Omnidirectional,GS1 DataBar Limited,GS1 DataBar Expanded,China Post(Hong Kong 2 of 5),Korea Post

二維條碼/2-D:

Codeblock A,Codeblock F,PDF417,Micro PDF417,GS1 Composite Codes, QR Code,Data Matrix,MaxiCode,Aztec,HANXIN

默認開啟碼制:

Codabar,Code39,Interleaved2of5,NEC2of5,Code93,Code128,GS1-128,UPC-A,UPC-E 0,EAN/JAN-13,EAN/JAN-8,GS1-DataBar,PDF417,QR,DM,Aztec

條碼精度Minimum Resolution

≥4mil

用戶環境參數/User Environment

工作溫度 Operating Temperature:

-20°C to 60°C

存儲溫度 Storage Temperature:

-30°C to 70°C

濕度 Humidity:

5% to 95% relative hum idity,non-condensing

抗震性 Shock Specifications:

Designed to withstand 1.2m(5’) drops

環境光免疫 Ambient Light Immunity:

0-100,000 Lux.

解碼范圍/Decode Ranges

5 mil (Code 39)

20mm-120mm

13 mil (Code 39)

30mm-270mm

Performance may be impacted by bar code quality and environmental conditions
